Grindrite ST2000 You’ve had comments, we’ve been listening. The all new ST2000 from Grindrite represents the next generation of inline tuning machines from the company that invented the concept. This universal wide stone/wide belt machine tunes everything from snowboards to nordic skis. Variable Speed Drives
The ST2000 uses an AC variable speed motor and controller for both power and flexibility. Stone speeds from 0 to 1000 RPM allow for even the finest race structures around, while the 5 Hp main motor has enough power to rip down even the most trashed bases. Since Grindrite machines are made in the US, you still have the convenience of standard single-phase power! DualZone Dressing System
This revolutionary dressing system operates in either pre-programmed fully-automatic mode or variable-speed mode with manual advance. In addition, the operator has the option of using a single- point diamond, for coarse structures, or a linear diamond, for more precise structures. The DualZone system gives the inexperienced operator the option of just hitting a button for pre-programmed structure or the experienced race technician the more choices than he’s ever imagined. |
New Coolant System
A new high-pressure 1/3 Hp, 90 psi, multi-stage booster is at the heart of the ST2000 water system, resulting is the cleanest structures possible. Additionally, a larger water tank, filter system and re-configured water flow keeps the coolant system cleaner than ever. Specifications Motors
Main: 5 Hp, 220VAC, three-phase, TEFC with electronic variable-speed drive
Feed: 1/4 Hp, 180VDC, variable speed, inline gear motor
Dresser: 1/8 Hp, 180VDC, variable-speed, right-angle gear motor
Pump: 1/3Hp, 220VAC, 90 psi, multi-stage booster pump Coolant System
Tank: 22 gallon, polyethylene w/ baffle (18 gallon operating capacity)
Filter: Dual Nylon mesh, removable/reusable
Spray Jets: 6 Marine Brass, non-clogging, 1.5 gpm flood jets Dimensions
Footprint: 29″ wide x 43″ long
Overall: 35″ wide x 45″ long x 65″ tall (feed in upright position)
Operating Area: 5′ x 16′
Weight: 1500 lbs Accessory Specs
Belt size: 12.75″ wide x 59″ long or 6″ x 59″
Stone: 13″ wide x 10″ diameter, universal Electrical Requirements
Voltage: Single-phase, 220 VAC, 50/60Hz
Supply Protection: 40 amp
Wire Provided: 10′ #10-AWG/3 SO |
